直線模組型號

不同系列的Thomson直線模組都可以配置在惡劣環境、高速和高精度應用中工作，同時兼顧性能、壽命和成本。RediMount電機安裝適配器套件現在是所有系統的標準配置，使得與直線模組匹配的電機的選型和安裝過程更快更容易。

直線模組型號

Movoparts直線模組型號

Movopart Linear slide actuator, a linear motion unit

專為運輸級應用（如包裝、物料搬運和工廠自動化）設計的經濟型直線單元。

了解更多 >

WH（SpeedLine）直線模組型號

導輪導向直線單元，設計用于吞吐量至關重要的高速物料搬運和包裝應用。

了解更多 >

WM（powerline)直線模組

滾珠導向直線單元，同時結合了高精度與剛度和硬度，適用于機床自動化和測試/測量等應用。

了解更多 >

直線工作臺

linear guide systems and linear motion tables

帶雙軌、4軸承結構的直線單元，專為最大化力矩負載和/或精度而設計。

了解更多 >

小型直線模組

小型直線單元，最適合醫療、實驗室自動化、輕量級包裝或物料搬運應用。

了解更多 >

MovoTrak? 7th Axis

The first ever true collaborative range extender for cobots, featuring collision detection settings for groundbreaking programming and control benefits.

Learn More >

傳統LMS 線性模組

了解更多 >

請讓Thomson幫您做出選擇！

線性滑軌是什么 >
Linear MOTIONEERING LMS 選型工具 >
Thomson機械運動解決方案綜述手冊 >

對于要求高速度、高負載、高剛度和高剛性精密直線運動的機械設計，直線模組是理想的解決方案。

為什么選擇Thomson直線運動系統？

從高空間利用率系統到大型堅固解決方案，Thomson廣泛的電動滑臺都可針對您的高精密應用進行優化配置，滿足各種嚴苛環境的要求。我們的系統標配RediMount?電機安裝適配器套件，能夠充分兼顧性能、壽命和成本。

直線模組定制選項

當Thomson標準線性模組不能滿足您的設計要求時，我們的工程師可與您合作，設計定制解決方案。事實上，我們的直線運動系統在構建時都考慮到定制需求，可以通過靈活搭配模塊，快速打造出適合您應用的高性價比解決方案。

直線模組選型不知從哪里入手?

Thomson提供豐富的在線資源，無論您的購買決策處于哪個階段，都可以為您提供幫助：

產品選型

網絡培訓視頻

培訓

技術文章

常見問題解答

視頻：如何使用Thomson RediMount套件將電機安裝到直線模組上

您無需再浪費寶貴的時間去尋找適合您設計的電機法蘭套件，并將其組裝起來。使用新的預裝RediMount適配器套件，只需訂購，然后在收貨后用螺栓將其固定至電機或齒輪。本視頻將向您展示具體操作步驟。

How to Mount Your Motor to a Linear Motion System Using the Thomson RediMount Kit

視頻：直線系統：限位開關設置

Thomson工程師展示了如何將限位開關軌道安裝至所有直線單元。如果您訂購的是帶直線單元的限位開關套件，則它是預安裝的。但如果要調整這些傳感器或單獨訂購，則安裝也很容易。開關可以選擇常閉或常開，并配有保護蓋。

視頻：耐沖洗的棱軌導向系統

Thomson推出了配備沖洗保護選項的MOVOPART M75皮帶驅動棱軌導向單元。棱形導軌是一種工程聚合物，可沿擠壓型材滑動。這種類型的軸承非常適合沖擊負載、低噪音或者存在沖洗或腐蝕性環境的應用。

視頻：高速度WH型直線模組

Thomson推出了WH SpeedLine皮帶驅動導輪導向直線運動系統。這些單元非常適合采用多方向或多軸配置的高速應用。可選50和120 mm導軌寬度，速度可達10 m/s，行程可達11米。

視頻：高精度WM型直線模組

WM系列具有內部活動滾珠絲杠支撐，允許長行程長度和高速運行。因此非常適合用于需要剛度、剛性和/或精度的應用，如機床自動化或測試和測量。Thomson可以提供長達11米的單元……

技術文章

為了應對環境可持續性、房地產價格不斷攀升以及能耗等住宅問題，弗吉尼亞理工大學的FutureHaus工程團隊設計出了屢獲大獎的智能房屋原型，該原型使用了Thomson直線運動系統。
基本的直線運動系統中包含一系列組件，而這些組件內又進一步包含無數的子系統。本文旨在幫助設計工程師理解設計系統時的關鍵注意事項。
由于直線運動系統會暴露在各種極端環境和條件下，因此謹慎的系統選型和周密的工程審查是避免潛在風險的關鍵。
